Ensuring a Perfect Fit: Installing Kitchen Base Units on Uneven Floors

A detailed guide on handling uneven floors when installing kitchen base units, ensuring both functionality and aesthetics are maintained.

Understanding the Basics

Every kitchen starts with a vision. But turning this vision into reality requires knowledge of measurements, designs, and the challenges presented by the space, such as uneven floors.

Base units form the backbone of any kitchen, with a standard height of 720mm, providing a foundation around which the rest of the kitchen revolves.

Tackling Uneven Floors

Uneven floors are a common hurdle in both modern and older properties. In our two decades of industry experience, we've encountered floors with up to a 50mm height difference across a single unit run.

But fear not, adjustable feet accompanying all base units are your saviour, allowing for adaptations to maintain a level surface.

Effective Installation Techniques on Uneven Floors

Begin by positioning the units roughly where they'll permanently reside. Then, use connector bolts or screws to affix the units together.

This approach enables you to level the units collectively, producing a harmonious alignment. Once they're perfectly levelled, you can then securely attach the entire run of units to the wall.

In certain instances, the default leg height might not be adequate. Should you require a reduced height, consider trimming the legs; alternatively, you can remove the legs entirely and utilise blocks for the appropriate support level.

For height increases, kitchen installers might place timber shims under the legs, ensuring stability while achieving the desired elevation.

Adjusting to Perfection

The adjustable legs of a base unit generally add 150mm to the unit height, making a combined total of 870mm. However, depending on the unevenness of the floor, the finished height, excluding the worktop, could range between 850 to 890mm.

The inclusion of the worktop thickness adds another dimension to the equation, generally contributing an additional 40mm to the total height.

Utilising Half Height Base Units

Half height base units, measuring at 360mm, offer unique solutions and versatility in design.

They are particularly handy when incorporating bench seating into your kitchen layout, ensuring a seamless integration with the rest of the design.

Mastering the Measurements

In kitchen design, the precision of measurements dictates the success of the installation. Among these, base units are paramount. They form the sturdy foundation upon which the entirety of your kitchen rests.

The go-to height for standard kitchen base units stands at 720mm. Factor in uneven floors, a frequent issue in older homes, and the role of the adjustable feet on these units becomes critical.

These adjustable legs typically measure 150mm. Combined with the base unit height, we reach a total of 870mm. Don't forget to add the thickness of the worktop, which can introduce another 40mm.

And for those considering half-height base units, these come in at a height of 360mm, tailored for designs that incorporate bench seating.

Conclusion​

Equipping yourself with the right knowledge and tools can turn the task of installing base units on uneven floors from daunting to doable.
