CDA CCH60BL - Canopy extractor, Touch or Remote Control, Hob Connect (HN6860FR)

The CCH60BL canopy hood comes with HoodConnect, allowing seamless operation between the extractor and HN6860FR induction hob, allowing your hood to auto operate alongside the induction hob. The sleek black finish provides a modern look, whilst also offering these great features: A Rated, quieter operation, touch control and remote control, LED lighting and 3 speeds + intensive boost.

Please note: To install this extractor, significant modifications will need to be made to the unit your are fitting it to. Although it is possible to fit this extractor into a 600mm Wide unit, it may be easier to fit in a larger one. Please speak to one of our advisors for more information.

Features

• Speeds: 3 speeds plus booster
• Ducted/re-circulating installation
• Touch control
• Remote control
• Boost function
• Light Dimmer
• HoodConnect
• Adjustable light temperature
• Off Timer

Technical Specification

• Outlet diameter: 150mm mm
• Required height over gas hobs: 650 mm (min)
• Required height over electric hobs: 450 mm (min)

Extraction Rates And Noise

• Extraction rate at first speed: 245 m³/hr
• Extraction rate at second speed: 330 m³/hr
• Extraction rate at fourth speed: 665 m3/hr
• Noise level at second speed: 56 dBA
• Noise level at first speed: 49 dBA
• Extraction rate at third speed: 415 m3/hr
• Noise level at third speed: 62 dBA
• Noise level at fourth speed: 69 dBA

Filters

• Aluminium grease filter: 1
• Number of grease filters: 2

Lighting

• Type of light: LED

Energy

• Energy rating: A

Dimensions

• Width: 589mm
• Depth: 290mm
• Height: 320mm

Misc Information

• WEEE Category: 1




Please note: To install this extractor, significant modifications will need to be made to the unit your are fitting it to. Although it is possible to fit this extractor into a 600mm Wide unit, it may be easier to fit in a larger one. Please speak to one of our advisors for more information.
